Epson LX-350 Dot Matrix Printer
Monochrome - 9-pin 80 -column - 390 Mono - USB - Parallel - Serial
Epson LX-350 Dot Matrix Printer
Monochrome - 9-pin 80 -column - 390 Mono - USB - Parallel - Serial
- Brand: Epson
- MPN: C11CC24041
- Part #: PTREPA2378935
- UPC:
- Brand: Epson
- MPN: C11CC24041
- Part #: PTREPA2378935
- UPC:
COMBO DEALS: Buy Together and SAVE!
Matthews EKON Premium Quality Office Printer Paper A4 - 80gsm White 210x297mm 500 Sheets per Ream A...
$6.72 +GST
$7.73
Features
Specifications
Reviews
Accessories
Delivery & Pick-up
Returns & Warranty
Popular Printers
Epson LX-350 Dot Matrix Printer Monochrome - 9-pin 80 -column - 390 Mono - USB - Parallel - Serial
- Brand: Epson
- MPN: C11CC24041
- Part #: PTREPA2378935
Product URL: https://www.pbtech.co.nz/product/PTREPA2378935/Epson-LX-350-Dot-Matrix-Printer-Monochrome---9-pin
Branch | New Stock | On Display |
---|---|---|
Albany | 0 | |
Glenfield | 0 | |
Queen Street | 0 | |
Auckland Uni | 0 | |
Newmarket | 0 | |
Westgate | 0 | |
Penrose | 0 | |
Henderson (Express) | 0 | |
St Lukes | 0 | |
Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Head Office | 0 | |
Hornby | 0 | |
Christchurch Central | 0 |
Features
The highly reliable Epson LX-350 has a mean time between failure of 10,000 operating hours, and is ideal for front and back office applications needing continuous paper or multi-part stationery. A very economical printer to run, the LX-350 helps save money with its high ribbon yield of 4 million characters and its low power consumption. Using just 1.1W in sleep mode and 27W when powered on, the LX-350 is qualified by ENERGY STAR for its excellent energy efficiency. Easy to integrate, the LX-350 has Parallel, Serial and USB interfaces as standard, and will fit neatly onto desks thanks to its compact design and cable management system.
KEY FEATURES & BENEFITS
- High reliability: MTBF of 10,000 operating hours
- Power-efficient: 1.1W on standby, 27W powered on
- Economical: Ribbon yield of 4m characters
- Easy integration: Parallel, Serial and USB interfaces
- Compact design: Fits neatly onto desks
Specifications
Header
Printer Type
Impact Dot Matrix
Product Name
Epson LX-350
Product Code
C11CC24041
Printing Method
Impact dot matrix
Number of Pins in Head
9 pins
Print Direction
Bi-directional with logic seeking
Print Speed
High Speed Draft
10 CPI - 347 cps
12 CPI - 357 cps
15 CPI - 390 cps
High Speed Draft Condensed
17 CPI - 383 cps
20 CPI - 298 cps
Draft
10 CPI - 260 cps
12 CPI - 312 cps
15 CPI - 223 cps
Draft Condensed
17CPI - 222 cps
20 CPI - 260 cps
Draft Emphasized
10 CPI - 130 cps
Print Characteristics
Bitmap Fonts
Epson Draft : 10, 12, 15 CPI
Epson Roman : 10, 12, 15 CPI, Proportional
Epson Sans Serif : 10, 12, 15 CPI, Proportional
Bar Code Font
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A
UPC-E, Code 39, Code 128, PostNet
Printable Columns
PITCH (CPI)
Character per line
10 CPI
80
12 CPI
96
15 CPI
120
17 CPI
137
20 CPI
160
Paper Handling
Paper Path
Manual Insertion - Rear in, Top out
Tractor - Rear in, Top out
Paper Size
Cut Sheet
- Manual Insertion
Width : 100 ~ 257 mm (3.9 ~ 10.1")
Length: 100 ~ 364 mm (3.9 ~ 14.3")
Thickness: 0.065 ~ 0.14 mm (0.0025 ~ 0.0055")
_
- Cut Sheet (Multi Part)
Width : 100 ~ 257 mm (3.9 ~ 10.1")
Length: 100 ~ 364 mm (3.9 ~ 14.3")
Thickness: 0.12 ~ 0.39 mm (0.0047 ~ 0.015") (Total)
Envelope
- No.6
Width : 165 mm (6.5")
Length: 92 mm (3.6")
Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205") (Total)
_
- No.10
Width : 241 mm (9.5")
Length: 105 mm (4.1")
Thickness: 0.16 ~ 0.52 mm (0.0063 ~ 0.0205") (Total)
Continuous Paper (Single sheet and Multi Part)
Width : 101.6 ~ 254 mm (4.0 ~ 10.0")
Length: 101.6 ~ 558.8 mm (4.0 ~ 22.0")
Thickness: 0.065 ~ 0.39 mm (0.0025 ~ 0.015") (Total)
Roll Paper
Width : 216 mm (8.5 ")
Thickness: 0.07 ~ 0.09 mm (0.0028 ~ 0.0035")
Paper Feeding
Standard
- Friction, Push
- Tractor
Optional
- Roll Paper Holder
Copies
Original + 4 copies
Line Spacing
4.23 mm (1/6 inch) or programmable in increments of 0.118 mm (1/216 inch)
Interface
Standard
Bi-directional parallel interface (IEEE-1284 nibble mode supported)
Serial I/F
USB (ver 2.0 full speed) I/F
Ribbon Cartridge
Colour : Black
Type: Fabric
Ribbon Life: Approx. 4 million characters (Draft 10 cpi 14 dots/character)
General
Accoustic Noise
Approx. 53dB (A) (ISO 7779 pattern)
Input Data Buffer
128 KByte
Control Panel
4 switches, 5 LEDs
Temperature
5 ~ 35 °C
Humidity
10 ~ 80 % RH
Reliability
MVBF (Mean Print Volume Between Failure)
Approx. 12 million lines (Except print head)
MTBF (Mean Time Between Failure)
Approx. 10,000 POH (25% duty cycle)
Print Head Life
Approx. 400 million strokes/wire
Electrical Specifications
Rated Voltage
AC 120 V / AC 220 - 240 V
Rated Frequency
50 Hz / 60 Hz
Power Consumption
Approx. 27 W (ISO/IEC 10561 Letter pattern)
Approx. 1.1 W in sleep mode
0 W in powered off mode
Approx. 0.3W in auto off mode
ENERGY STAR COMPLIANT
Dimensions
WIDTH
362 mm (348 mm Except knob)
DEPTH
275 mm
HEIGHT
154 mm
WEIGHT
Approx. 4.1 kg
PRINTER DRIVER / UTILITY
OS
Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®
UTILITY
Epson Status Monitor 3 (Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®)
Epson Printer Setting (Microsoft® Windows® 2000 / XP / 7, Microsoft® Windows Vista®)
