TP-Link TL-SF1005P 5-Port 10/100M Unmanaged PoE Switch, 4-Port PoE (Max 58W)

TP-Link TL-SF1005P 5-Port 10/100M Unmanaged PoE Switch, 4-Port PoE (Max 58W)

  • Brand: TP-Link
  • MPN: TL-SF1005P
  • Part #: SWHTPL1027
  • UPC:
  • Form Factor:Desktop
  • Management Level:Unmanaged
  • Number of Ports:5 Ports
  • PoE:Yes
  • PoE Ports:4 Ports
  • PoE Budget:58 Watts
  • Stacking:No
  • Uplink Ports:0
$6600$7590
 +GST  inc GST

Store Pickup: Select your store to check availability
Delivery: Order now and it ships tomorrow
When will I receive it?

Features

What This Product Does

TL-SF1005P is a 5 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.


Power over Ethernet

4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).


Overload Arrangement

TL-SF1005P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 58W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.


Port Priority Function

Priority (port-1=port-2=port-3>port-4): This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 58W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 12W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 12W, no power will be supplied to Port 4.


Easy To Use

TL-SF1005P is easy to install and use. It requires no configuration and installation. With desktop design, outstanding performance and quality, the TP-Link's TL-SF1005P 5-Port 10/100Mbps Desktop Switch with 4-Port PoE is an ideal choice for expanding your home or office network.


Code Model Features
Speed Total Ports PoE PoE+ Power Budget Management SFP
SWHTPL1027 TL-SF1005P 100Mbps 5 4 - 58W No N/A
SWHTPL1011 TL-SF1008P 100Mbps 8 4 - 57W No N/A
SWHTPL1028 TL-SG1005P Gigabit 5 4 - 56W No N/A
SWHTPL1020 TL-SG1008P Gigabit 8 4 - 55W No N/A
SWHTPL1001 TL-SG108PE Gigabit 8 4 - 55W Yes N/A
SWHTPL1012 TL-SG1008PE Gigabit 8 - 8 126W No N/A
SWHTPL1021 TL-SG1016PE Gigabit 16 - 8 110W Yes N/A
SWHTPL2210P T1500G-10PS Gigabit 10 8 - 53W Yes 2
SWHTPL1500 T1500G-10MPS Gigabit 10 - 8 116W Yes 2
NETTPL0028 T2500G-10MPS Gigabit 10 - 8 116W Yes 2
SWHTPL2425 T1600G-28PS Gigabit 28 - 24 180W Yes 4
SWHTPL3425 T2600G-28MPS Gigabit 28 - 24 384W Yes 4
SWHTPL1016 T1600G-52PS Gigabit 52 - 48 384W Yes 4

Specifications

HARDWARE FEATURES

Interface
5 10/100Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100O STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100O STP (maximum 100m)
Fan Quantity:
Fanless
External Power Supply:
External Power Adapter(Output: 48VDC / 1.25A)
PoE Ports (RJ45):
Standard: 802.3 af compliant
PoE Ports:
Port1- Port4
Power Supply:
58W
Mac Address Table:
2K
Switching Capacity:
1Gbps
Dimensions (W x D x H):
3.9 x 3.9 x 1.0 in. (99.8 x 98 x 25 mm)
Transmission Distance:
Store-And-Forward
Max Power Consumption:
63.51W (max. with 58w PD connected)
1.70W (max. no PD connected)

SOFTWARE FEATURES

Transmission Method:
Store-And-Forward
Advanced Functions:
Compatible With IEEE 802.3af Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode

OTHERS

Certification:
FCC, CE, RoHS
Package Contents:
TL-SF1005P, Power Adapter, User Guide
Consumption:
1.70 watts (max. no PD connected)
63.51 watts (max. with 58w PD connected)
Environment:
Operating Temperature: 0C~40C (32F~104F)
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90%RH non-condensing
Storage Humidity: 5%~90%RH non-condensing

Manufacturer Part No: TL-SF1005P Brand: TP-Link Product Type: -
UPC - Product Family: - Shipping Weight: 0.81 kg
PB Part No: SWHTPL1027 Product Model: TL-SF1005P

Warranty: 36 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
