Arctic Silver 5 High-Density Silver AS5-3.5G Thermal Compound 3.5-Gram Tube thermal grease paste Made With 99.9% Pure Silver
Arctic Silver 5 High-Density Silver AS5-3.5G Thermal Compound 3.5-Gram Tube thermal grease paste Made With 99.9% Pure Silver
- Brand: Arctic
- MPN: AS-AS5-35
- Part #: FANARC10535
- UPC: 832199001014
Select your store to check availability
- Brand: Arctic
- MPN: AS-AS5-35
- Part #: FANARC10535
- UPC: 832199001014
What PB Tech customers are saying about this product...
See More ReviewsCustomer Review Summary
"Customers praise the Arctic Thermal Paste due to its effective heat conductivity leading to noticeable improvements in CPU temperatures. Valued for its reliability and worthiness g ...view more"
"I bought this for a new build PC and had no issues with it. There's also plenty left over for next time."
"Applies like thermal paste should, temps appear to be running good. Can't complain :)"
COMBO DEALS: Buy Together and SAVE!
Cruxtec ADS01 flammable Clean Range Compressed Air Duster 400ml Spray Can with Nozzle Dust-off...
$10.86 +GST
$12.49
Dynamix CAB150B Cable Tie 150mm x 2.5mm Bag of 100 self-locking Nylon cable tie Black Colour
$2.48 +GST
$2.85
ADATA C008 USB Flash Drive - 16GB - White / Blue USB 2.0
$4.21 +GST
$4.84
Posh TA-001 ESD Anti Static Wrist Strap Band - 1.8M (Blue)
$6.50 +GST
$7.48
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Thermal Paste
Arctic Silver 5 High-Density Silver AS5-3.5G Thermal Compound 3.5-Gram Tube thermal grease paste Made With 99.9% Pure Silver
- Brand: Arctic
- MPN: AS-AS5-35
- Part #: FANARC10535
- UPC:832199001014
Product URL: https://www.pbtech.co.nz/product/FANARC10535/Arctic-Silver-5-High-Density-Silver-AS5-35G-Therma
Branch | New Stock | On Display |
---|---|---|
Albany | 20+ | |
Glenfield | 20+ | |
Queen Street | 16 | |
Auckland Uni | 9 | |
Newmarket | 16 | |
Westgate | 20+ | |
Penrose | 20+ | |
Henderson (Express) | 13 | |
St Lukes | 20+ | |
Manukau | 20+ | |
Hamilton | 20+ | |
Tauranga | 11 | |
New Plymouth | 7 | |
Palmerston North | 20+ | |
Petone | 20+ | |
Wellington | 20+ | |
Head Office | 20+ | |
Hornby | 20+ | |
Christchurch Central | 20+ |
Features
Arctic Silver® 5 - High-Density Polysynthetic Silver Thermal Compound
Introducing Arctic Silver 5 With its unique high-density filling of micronized silver and enhanced thermally conductive ceramic particles, Arctic Silver 5 provides a new level of performance and stability. Now available at Arctic Silver dealers worldwide, Arctic Silver 5 is definitely The New Reference. Arctic Silver 5 is optimized for use between modern high-power CPUs and high performance heatsinks or water-cooling solutions.
Contains 99.9% pure silver:
Arctic Silver 5 uses three unique shapes and sizes of pure silver particles to maximize particle-to-particle contact area and thermal transfer.
High-Density:
Arctic Silver 5 contains over 88% thermally Conductive filler by weight. In addition to micronised silver, Arctic Silver 5 also contains sub-micron zinc oxide, aluminium oxide and boron nitride particles. These thermally-enhanced ceramic particles improve the compound's performance and long-term stability.
Controlled Triple-Phase Viscosity:
Arctic Silver 5 does not contain any silicone. The suspension fluid is a proprietary mixture of advanced polysynthetic oils that work together to provide three distinctive functional phases. As it comes from the tube, Arctic Silver 5's consistency is engineered for easy application. During the CPU's initial use, the compound thins out to enhance the filling of the microscopic valleys and ensure the best physical contact between the heatsink and the CPU core. Then the compound thickens slightly over the next 50 to 200 hours of use to its final consistency designed for long-term stability. (This should not be confused with conventional phase change pads that are pre-attached to many heatsinks. Those pads melt each time they get hot then re-solidify when they cool. The viscosity changes that Arctic Silver 5 goes through are much more subtle and ultimately much more effective.)
Not Electrically Conductive:
Arctic Silver 5 was formulated to conduct heat, not electricity. (While much safer than electrically conductive silver and copper greases, Arctic Silver 5 should be kept away from electrical traces, pins, and leads. While it is not electrically conductive, the compound is very slightly capacitive and could potentially cause problems if it bridges two close-proximity electrical paths.)
Absolute Stability:
Arctic Silver 5 will not separate, run, migrate, or bleed.
Compliancy:
RoHS Compliant.
Specifications
Thermal Conductance
>350,000W/m2 C (0.001 inch layer)
Thermal Resistance
<0.0045C-in2/Watt (0.001 inch layer)
Average Particle Size
<0.49 microns <0.000020 inch
Extended Temperature Limits
Peak: -50C to >180C
Long-Term: -50C to 130C
Coverage area
Sold in 3.5 gram Tube. The 3.5 gram tube contains enough compound to cover at least 15 to 25 small CPU cores, or 6 to 10 large CPU cores, or 2 to 5 heat plates. At a layer 0.003" thick, the 3.5 gram tube will cover approximately 16 square inches.
Important Reminder
Due to the unique shape and sizes of the particles in Arctic Silver 5's conductive matrix, it will take a up to 200 hours and several thermal cycles to achieve maximum particle to particle thermal conduction and for the heatsink to CPU interface to reach maximum conductivity. (This period will be longer in a system without a fan on the heatsink or with a low speed fan on the heatsink.) On systems measuring actual internal core temperatures via the CPU's internal diode, the measured temperature will often drop 2C to 5C over this "break-in" period. This break-in will occur during the normal use of the computer as long as the computer is turned off from time to time and the interface is allowed to cool to room temperature. Once the break-in is complete, the computer can be left on if desired.
Caution
We do not recommend using Arctic Silver 5 on the older slot type Intel Xeon processors with large multiple square inch CPU to heatsink interfaces. The huge contact area and large gaps between the processor and the heatsink require a thermal pad or thick mesh-reinforced paste. Arctic Silver 5 can be used on socket type Xeons without a problem.
